| Model |
FWS-30 |
| Mode |
Reciprocating oscillation + thermostatic water bath |
| Function |
Operating Temp Range |
RT～100℃ |
| |
Tem. Resolution Ratio |
0.1℃ |
| |
Tem. Motion |
±0.1℃ |
| |
Tem. Uniformity |
±0.2℃ |
| |
Reciprocal Oscillation Amplitude |
16 or 24mm (Ex-factory is 16mm) |
| |
Reciprocating Frequency Range |
20～180（r/min） |
| |
Reciprocating Frequency Accuracy |
±1rpm |
| Structure |
Water Tank |
Mirror stainless steel |
| |
Outer Shell |
Cold rolling steel electrostatic spraying exterior |
| |
Upper Cover |
Mirror stainless steel |
| |
Insulating Layer |
Polyurethane |
| |
Heater |
Stainless Steel Heater |
| |
Driving Mode |
Crankshaft+ double link + four wheels |
| |
Shelf |
Mirror stainless steel |
| |
Power rating |
1.5kW |
| Controller |
Tem. Control Mode |
LCD PID Intelligent control |
| |
Reciprocating Control Mode |
| |
Setting Mode |
Touch button setting |
| |
Tem. Display Mode |
LCD Display |
| |
Speed Display Mode |
| |
Timer |
0～9999 min |
| |
Operation Function |
Fixed value operation, timing function, auto stop, quickly stop start |
| |
Temperature Sensor |
Pt100 |
| |
Speed Sensor |
Hoare |
| |
Additional Function |
Deviation correction, menu keys locked, power-off memory |
| Safety device |
over temperature alarm, menu locked, water full or shortage protection, Motor shaft lock protection; |
| Specification |
Water Tank Size (W*L*H)(mm) |
500*310*200 |
| |
Exterior Size (W*L*H)(mm) |
828*360*425 |
| |
Packing Size (W*L*H)(mm) |
908*440*505 |
| |
Spring Shock Basket Size（mm）Size (ml /piece) |
395*250 |
| |
Shock Basket Largest Single |
100ml*12/250*8/500*6 |
| |
Inside Volume |
31L |
| |
Shock Basket Bearing |
5kg/layer |
| |
Current Rating （50Hz） |
AC220V/6.8A |
| |
NW/GW (kg） |
20/30 |
| Accessories |
Water bath flask seat, tube rack
|
