Art No.

JSDS-300C

JSDS-420C

JSDS-960C

Chamber Volume (Capacity)

300 L

432 L

964 L

Dimensions

Inner

500 x 500 x 1200

600 x 600 x 1200

1200 x 600 x 1200

W x D x H mm

Outer

690 x 835 x 1985

790 x 935 x 1985

1390 x 935 x 1985

Temperature

Range

+10 ^oC ~ 70 ^oC w/o Humidification

Accuracy

± 0.3 ^oC at 20.0 ^oC, 60% RH

Uniformity

± 1.0 ^oC at 20.0 ^oC, 60% RH

Humidity

Range

30 ~ 85% RH

Accuracy

± 3.0 % RH at 20.0 ^oC 60% RH

Uniformity

± 6.0 % RH at 20.0 ^oC 60% RH

Illumination

Type

Fluorescent lamp on/off for observation

Lamp

3 x 36W FPL

3 x 36W FPL

4 x 36W FPL

Controller

Programmable PID Control 11 segments 999 cycle repeatable

Sensors

Temp

Class A Pt-100 Ω Sensor

Humidity

Electronic Humidity Sensor

Number of shelves / Max. No.

3 / 35

3 / 35

6 / 35

Heater Capacity

3.1 kW

3.5 kW

6.0 kW

Refrigeration System

CFC-Free Air Cooled Hermetically Sealed Compressor

Electric Requirement

220VAC 50/60Hz 1P

Power Rating

19 Amp

21 Amp

34 Amp

Power Plug

30 AMP

30 AMP

50 AMP
